LED Ceiling Light

IP65 Sensor Panel Light

SPS026
36W 48W
IP Rated: IP65
CRI>80
IP65 LED Sensor Panel Light
INQUIRY

IP65 Antibacterial Panel Series

Thanks for choosing IP65 Antibacterial panel Series. This light combines innovative optical and mechanical design features to achieve a soft and uniform light distribution, special used in pharmaceutical factory and hospital. For this item, IP54 version is optional, front surface is IP65, backsize and driver is IP40.

◈ FEATURES

• Antibacterial function allow the panel used in the hospital, food factory and etc.;

• Dustproof and water proof,

• Antibacterial test certifiates available;

◈ ADVANTAGE

TUV Listed CE, CB, and RoHS, SAA,ISO9001;
Front face+backside+driver, whole fixture IP65 anti-bacteria,totally Waterproof and dust proof;
Special used in pharmaceutical factory, hospital;
IP54 version is optional, front surface is IP65, backsize and driver is IP40;
IP65 test report, IK07 test report, clean room test report are available.

◈ SPECIFICATION

IP65 Antibacterial LED Panel Light

Photometric Parameters

NO.

Project

Parameter

1

LED

High luminous ﬂux SMD LED Samsung/Osram

2

Luminous Efﬁciency

120 Lm/W

3

CCT

3000K-6500K (warm white, natural white, cool white)

4

CRI

≥80

5

Beam Angle

120°

6

UGR

<19

7

LED Lifespan

≥50000 Hours

Electrical Parameters

8

Driver Input Voltage

AC220-240V /50-60Hz

9

OutputVoltage

DC30-40V

10

Power Supply Efﬁciency

≥88%

11

Power Factor

≥0.9

12

Protection Class

Class II

General Parameters

13

Rating IP

IP65

14

Material

Aluminum + PMMA

15

Frame Finishing

White

16

Installation

Recessed/Pendant

17

Working Temperature

-20～+45℃

18

Storing Temperature

-40～+60℃

19

Working Humidity

15%~90%RH

◈ SIZE

Efficiency

Model No.

Wattage

Luminous flux

CRI

LED

Dimension

100lm/W

WIPV606036

36W

3600lm

80Ra

SMD2835

595x595x10mm

WIPV626236

36W

3600lm

80Ra

SMD2835

620x620x10mm

WIPV3012036

36W

3600lm

80Ra

SMD2835

295x1195x10mm

100lm/W
WIPV606048

48W

4800lm

80Ra

SMD2835

595x595x10mm

WIPV626248

48W

4800lm

80Ra

SMD2835

620x620x10mm

WIPV3012048

48W

4800lm

80Ra

SMD2835

295x1195x10mm

◈ APPLICATION

♦ Commercial Offices

♦ Retail/Shopping Malls

♦ Clean room/hospital
